Escalator
parameters
Escalator 30°
|
Travelling Height |
Weight聽 |
Support Load |
Power |
Transport Demension |
||
|
|
|
R1 |
R2 |
|
|
|
|
H |
KN |
KN |
KN |
v=0.5m/s |
H |
I |
|
3000 |
57 |
46 |
41 |
5.5 |
2172 |
11177 |
|
3500 |
60 |
49 |
44 |
|
2217 |
12165 |
|
4000 |
63 |
52 |
47 |
|
2254 |
13155 |
|
4500 |
67 |
56 |
50 |
|
2284 |
14146 |
|
5000 |
70 |
59 |
53 |
8 |
2309 |
15138 |
|
5500 |
74 |
62 |
56 |
|
2330 |
16131 |
|
6000 |
77 |
65 |
59 |
|
2348 |
17125 |
|
3000 |
59 |
52 |
47 |
5.5 |
2066 |
10788 |
|
3500 |
63 |
56 |
50 |
|
2101 |
11778 |
|
4000 |
67 |
60 |
54 |
8 |
2130 |
12769 |
|
4500 |
70 |
64 |
57 |
|
2153 |
13762 |
|
5000 |
74 |
68 |
60 |
|
2172 |
14755 |
|
5500 |
78 |
74 |
66 |
11 |
2188 |
15750 |
|
6000 |
81 |
78 |
69 |
|
2201 |
16745 |
|
3000 |
63 |
59 |
53 |
8 |
2066 |
10788 |
|
3500 |
67 |
64 |
57 |
|
2101 |
11778 |
|
4000 |
71 |
68 |
61 |
|
2130 |
12769 |
|
4500 |
75 |
73 |
65 |
|
2153 |
13762 |
|
5000 |
79 |
79 |
71 |
11 |
2172 |
14755 |
|
5500 |
83 |
84 |
75 |
|
2188 |
15750 |
|
6000 |
86 |
88 |
79 |
|
2201 |
16745 |
Escalator 35°
|
Travelling Height |
Weight聽 |
Support Load |
Power |
Transport Demension |
||
|
|
|
R1 |
R2 |
|
|
|
|
3000 |
54 |
43 |
39 |
5.5 |
2291 |
10458 |
|
3500 |
57 |
46 |
41 |
|
2345 |
11309 |
|
4000 |
60 |
49 |
44 |
|
2389 |
12163 |
|
4500 |
64 |
52 |
46 |
|
2425 |
13019 |
|
5000 |
67 |
54 |
49 |
|
2456 |
13877 |
|
5500 |
70 |
57 |
51 |
8 |
2481 |
14737 |
|
6000 |
73 |
60 |
54 |
|
2503 |
15598 |
|
3000 |
56 |
49 |
44 |
5.5 |
2177 |
10073 |
|
3500 |
60 |
52 |
47 |
|
2219 |
10926 |
|
4000 |
63 |
56 |
50 |
8 |
2253 |
11782 |
|
4500 |
66 |
59 |
53 |
|
2281 |
12640 |
|
5000 |
70 |
62 |
56 |
|
2304 |
13500 |
|
5500 |
73 |
65 |
59 |
|
2324 |
14362 |
|
6000 |
76 |
69 |
61 |
11 |
2340 |
15224 |
|
3000 |
60 |
56 |
50 |
5.5 |
2177 |
10073 |
|
3500 |
64 |
60 |
53 |
8 |
2219 |
10926 |
|
4000 |
67 |
64 |
57 |
|
2253 |
11782 |
|
4500 |
71 |
67 |
60 |
|
2281 |
12640 |
|
5000 |
74 |
71 |
67 |
11 |
2304 |
13500 |
|
5500 |
78 |
77 |
69 |
|
2324 |
14362 |
|
6000 |
82 |
81 |
72 |
|
2340 |
15224 |
